172

Chapter 5     Using Snort with MySQL

Back Orifice detection brute force: DISABLED

Using LOCAL time

database: compiled support for ( mysql )

database: configured to use mysql

database:          user = rr

database: database name = snort

database:          host = localhost

database:   sensor name = 10.100.1.111

database:     sensor id = 1

database: schema version = 105

database: using the "log" facility

886 Snort rules read...

886 Option Chains linked into 99 Chain Headers

0 Dynamic rules

+++++++++++++++++++++++++++++++++++++++++++++++++++

Rule application order:  >activation >dynamic >alert >pass

>log

          == Initialization Complete ==

 *> Snort! <*

Version 1.8.6 (Build 105)

By Martin Roesch (roesch@sourcefire.com, www.snort.org)

The name of the database, the name of user and the host where the database is

installed are all listed in the output. The schema version is saved in the schema table in

MySQL database.

5.1.8

Step 8: Logging to Database

After configuring the database properly, you should check if log and alert mes

sages are being saved in the database tables. We use the following two rules for Snort to

test the database.

alert ip any any  > any any (ipopts: lsrr; msg: \

   "LSRR Options set"; logto: "test";)

alert icmp any any  > 192.168.1.0/24 any (fragbits: D; \

   msg: "Dont Fragment bit set";)

To test these rules, we use the following two commands on a Microsoft Windows

machine. I have used Windows XP Home Edition for the sake of experiment.

ping  n 1  f 192.168.1.2

ping  n 1  j 192.168.1.2 192.168.1.2
