Chapter 3     Working with Snort Rules

Table 3 1 Well Known Port Numbers (continued)

Port Number

Description

110

POP3, used for e mail clients like Microsoft Outlook

161

SNMP

162

SNMP traps

443

HTTPS or Secure HTTP

514

Syslog

3306

MySQL

You can also look into /etc/services file on the UNIX platform to see more

port numbers. Refer to RFC 1700 for a detailed list at http://www.rfc editor.org/rfc/

rfc1700.txt. The Internet Corporation for Assigned Names and Numbers (ICANN) now

keeps track of all port numbers and names. You can find more information at http://

www.icann.org.

3.5.5

Direction

The direction field determines the source and destination addresses and port num

bers in a rule. The following rules apply to the direction field:

  A  > symbol shows that address and port numbers on the left hand side of the

direction field are the source of the packet while the address and port number

on the right hand side of the field are the destination.

  A <  symbol in the direction field shows that the packet is traveling from the

address and port number on the right hand side of the symbol to the address and

port number on the left hand side.

  A <> symbol shows that the rule will be applied to packets traveling on either

direction. This symbol is useful when you want to monitor data packets for

both client and server. For example, using this symbol, you can monitor all

traffic coming from and going to a POP or Telnet server.

3.6 Rule Options

Rule options follow the rule header and are enclosed inside a pair of parentheses. There

may be one option or many and the options are separated with a semicolon. If you use

multiple options, these options form a logical AND. The action in the rule header is

invoked only when all criteria in the options are true. You have already used options like

msg and ttl in previous rule examples. All options are defined by keywords. Some rule

options also contain arguments. In general, an option may have two parts: a keyword
