Rule Headers

85

rule determines which address is source and which one is destination. Refer to the expla

nation of the direction part to find more information about how this selection is made.

Following are some examples of how addresses are mentioned in Snort rules:

  An address 192.168.1.3/32 defines a single host with IP address 192.168.1.3.

  An address 192.168.1.0/24 defines a class C network with addresses ranging

from 192.168.1.0 to 192.168.1.255. There are 24 bits in the netmask, which is

equal to 255.255.255.0.

  An address 152.168.0.0/16 defines a class B network with addresses ranging

from 152.168.0.0 to 152.168.255.255. There are 16 bits in the netmask, which

is equal to 255.255.0.0.

  An address 10.0.0.0/8 defines a class A network with addresses ranging from

10.0.0.0 to 10.255.255.255. There are 8 bits in the netmask, which is equal to

255.0.0.0.

  An address 192.168.1.16/28 defines an address range of 192.168.1.16 to

192.168.1.31. There are 28 bits in the netmask field, which is equal to

255.255.255.240, and the network consists of 16 addresses. You can place only

14 hosts in this type of network because two of the total 16 addresses are used

up in defining the network address and the broadcast address. Note that the first

address in each network is always the network address and the last address is

the broadcast address. For this network 192.168.1.16 is the network address

and 192.168.1.31 is the broadcast address.

For example, if you want to generate alerts for all TCP packets with

TTL=100 going to web server 192.168.1.10 at port 80 from any source, you

can use the following rule:

alert tcp any any  > 192.168.1.10/32 80 (msg: "TTL=100"; \

 ttl: 100;)

This rule is just an example to provide information about how IP addresses are

used in Snort rules.

3.5.3.1

Address Exclusion

Snort provides a mechanism to exclude addresses by the use of the negation sym

bol !, an exclamation point. This symbol is used with the address to direct Snort not to

test packets coming from or going to that address. For example, the following rule is

applied to all packets except those that originate from class C network 192.168.2.0.
