Snort Installation Scenarios

25

In a production installation, you also need to implement startup and shutdown pro

cedures so that Snort automatically starts at boot time. If you are installing a precom

piled version for Linux, the installation procedure with RPM will take care of it. On

Microsoft Windows systems, you can start Snort as a service or put a batch file in the

startup group. Issues related to Microsoft Windows are covered in Chapter 8. The log

ging is done in text or binary files and tools like SnortSnarf can be used to analyze data.

SnortSnarf is discussed in Chapter 6 in detail.

2.1.3

Single Sensor with Network Management System Integration

In a production system, you can configure Snort to send traps to a network man

agement system. There are a variety of network management systems used in the enter

prise. The most popular commercial systems are from Hewlett Packard, IBM and

Computer Associates.

Snort integration into these network management systems is done through the use

of SNMP traps. When you go through the compilation process of Snort later in this chap

ter, you will learn how to build SNMP capability into Snort. Chapter 4 provides more

information about configuring SNMP trap destinations, community names and so on.

2.1.4

Single Sensor with Database and Web Interface

The most common use of Snort should be with integration to a database. The data

base is used to log Snort data where it can be viewed and analyzed later on, using a

web based interface. A typical setup of this type consists of three basic components:

1. Snort sensor

2. A database server

3. A web server

Snort logs data into the database. You can view the data using a web browser con

nected to the sensor. This scheme is shown in Figure 1 1 in Chapter 1. All three compo

nents can be present on the same system as shown in Figure 1 2 in Chapter 1.

Different types of database servers like MySQL, PostgresSQL, Oracle, Microsoft

SQL server and other ODBC compliant databases can be used with Snort. PHP is used

to get data from the database and to generate web pages.

This setup provides a very good and comprehensive IDS which is easy to manage

and user friendly. You have to provide a user name, password, database name and data

base server address to Snort to enable it to log to the database. In a single sensor

scheme where the database is running on the sensor itself, you can use  localhost  as
