Client tier

Java Application

Server tier

DB2 JDBC Type2

Driver

DB2

Database

DB2 CLI

DB2

Client

Figure 7 1   DB2 type 2 JDBC Driver

Note:

 The DB2 JDBC type 2 driver is J2EE certified for use with IBM

WebSphere Application Server, which means it conforms to J2EE

specifications.

DB2 JDBC type 3 driver

The DB2 JDBC type 3 driver also called the

applet or net protocol/all Java

driver

 and follows a three tiered approach. In the DB2 JDBC type 3 driver,

the Java standalone application or Java applet passes the JDBC database

requests through the network to the middle tier server where the DB2 applet

server is running. The DB2 applet server then translates the request (directly

or indirectly) to the database specific native connectivity interface to pass the

request to the database server. Figure 7 2 shows the various tiers involved in

DB2 JDBC type 3 driver. The DB2 JDBC server process is

db2jd

 and the

driver is available in the

db2java.zip

 in directory

sqllib/java

.

For using DB2 JDBC type 3 driver you need following properties:

drivername= COM.ibm.db2.jdbc.net.DB2Driver

URL= java:db2://servername:serverport/dbname

Note:

 Here servername and serverport are the applet server port.

Note:

 The JDBC type 3 driver is deprecated for DB2 UDB Version 8.
