Tomcat i7230A S5160

                                                                  Chapter 3: BIOS Setup

Resume On Time

When enabled, this allows the system to be worked up at a specified time. This time is

specified by the Resume Time parameter.

Off / On

Resume Time

This option allows the user to specify the time when the system is to wake up.

Power Button Behavior

This specifies the behavior of the system after the power button is pressed.

On/Off   This powers on / powers off the system after the power button is

pressed.

Wake/Sleep   This wakes the system from/puts the system to sleep.

Suspend Mode

This feature is used to select the mode of suspend mode.

Suspend / On

After Power Failure

Specifies the mode of operation after the system recovers from a power loss.

Enabled: This restores the system to the last state it was in before the

power loss occurred.

Disabled: This keeps the power switched off till the power button is

pressed.

3.6 Boot

Use this screen to select options for the Boot Settings Configuration.

46
