                                                       Chapter 2: Board Installation

WARNING

:

This new processor socket designed by

Intel is easily damaged. The processor has

to be installed very carefully to prevent the

contact pins of the socket from breaking. It

is strongly recommended that the

processor installation job to be handled by

an experienced technician.

2.

Pull the locking lever out of it's locked position and let it spring into the open position.

3.

Lift the metal cover to expose the socket interior and place the socket in as shown.

Pin 1

4.

Close the cover and return the locking lever to its locked position.

Cooling Fan Installation

After you have installed the processor, the heatsink should be installed to ensure that the

processor runs efficiently and does not overheat. Use the heatsink supplied for best results.

Follow these instructions to install the heatsink shown.
