58

Appendix A Specifications

Keyboard and pointing device

glish

84 /85 /88 key Windows keyboard

En

Ergonomically centered touchpad pointing device with 4 way

scroll button

I/O ports

Two type II / one type III CardBus PC Card slots

One RJ 45 jack (Ethernet 10/100)

One RJ 45 jack (V.92/56Kbps)

One DC in jack

One parallel port (ECP/EPP)

One external monitor port

One headphone/speaker/line out jack (3.5mm mini jack)

One microphone/line in jack (3.5mm mini jack)

Three USB ports

One IEEE 1394 port

One S video TV out (NTSC/PAL) port

One Fast Infrared port

One 100 pin docking port

Weight and dimensions

322(W) x 272(D) x 35.5/38 (H) mm; (12.7" x 10.7" x 1.4"/1.5") for

14.1" LCD

327(W) x 272 (D) x 36.8/39.3 (H) mm; (12.9" x10.7" x 1.45"/1.55")

for 15.0" LCD

2.95 kg (6.5lbs) for 14.1" LCD model / 3.18kg (7.0lbs) for 15.0" LCD

model

Environment

Temperature

Operating: 5 C ~ 35 C

Non operating:  20 C ~ 65 C

Humidity (non condensing)

Operating: 20% ~ 80% RH
