* @resin ejb.relation

sql column="DEPTID"

*

*

*/

public abstract Dept getDept();

/** @ejb:interface method view type="local" */

public abstract void setDept(Dept dept);

The

resin ejb.relation

tag has a single parameter (sql column) that points the

column involved in the relationship, that is, the foreign key. It assumes that the foreign

key is pointing to the primary key of the other side of the relationship.

Some vendor specific mappings take two parameters the foreign key and the name of

the column in the other table (Dept) that the foreign key points to. To put this in

perspective, let s show the actual SQL DDL for these tables.

CREATE TABLE DEPT (

DEPTID

INT

IDENTITY

PRIMARY KEY,

NAME

VARCHAR (80)

);

CREATE TABLE EMPLOYEE (

EMPID

INT

IDENTITY

PRIMARY KEY,

FNAME

VARCHAR (80),

LNAME

VARCHAR (80),

PHONE

VARCHAR (80),

DEPTID

INT,

CONSTRAINT

DEPTFK FOREIGN KEY (DEPTID)

REFERENCES DEPT (DEPTID)

);

The employee table has a foreign key

DEPTID

that references the department s

primary key

DEPTID

.

XDoclet and EJB technology: Working with Session

beans

Now that you defined some Entity beans let s create a session bean that access the

Enhance J2EE component reuse with XDoclets

Page 41 of 49
