Appendix

I MIC algorithm

G COMP/LIM module

Type

Parameter

SENS

ATTACK

LEVEL

COMP

Compressor for keeping dynamic range consistent.

THRSHOLD

RELEASE

LEVEL

LIMITER

Limiter for controlling signal peaks.

Parameter Description

Parameter Name

Setting Range

Parameter Description

SENS

0   15

Adjusts the compression input sensitivity.

ATTACK

0   15

Adjusts the compression attack speed.

LEVEL

1   8

Adjusts the module output level.

THRSHOLD

0   15

Adjusts the limiter action threshold.

Adjusts the time delay between the threshold crossing point and compression

RELEASE

0   15

finish.

G MIC PRE module

Type

Parameter

COLOR

TONE

LEVEL

DE ESSER

MIC PRE

Preamp for use with external mic

Parameter Description

Parameter Name

Setting Range

Parameter Description

1. Flat response

2. Lowcut only

3. Acoustic guitar characteristics

COLOR

1   6

4.

Acoustic guitar characteristics with low cut

5. Vocal characteristics

6. Vocal characteristics with low cut

TONE

0   10

Adjusts the tone.

LEVEL

1   8

Adjusts the module output level.

DE ESSER

0   10

Adjusts the amount by which vocal sibilants will be cut.

G 3 BAND EQ module

For an explanation of types and parameters, see the CLEAN, DIST, ACOU/BASS SIM, BASS algorithm.

G  ZNR module

For an explanation of types and parameters, see the CLEAN, DIST, ACOU/BASS SIM, BASS algorithm.

G VOL PDL module

For an explanation of types and parameters, see the CLEAN, DIST, ACOU/BASS SIM, BASS algorithm.

ZOOM MRS 802

148
