Chapter 7      Administration

Setup

Procedure

Step 1

Select Administration > Setup > Authentication Modules.

Step 2

From the drop down arrow, select an authentication module, then click Apply. A

Configuration dialog box appears for all selections except the Local module.

Step 3

Depending on the authentication module you selected, enter the following data,

then click Submit:

Radius module or TACACS+ module:

  Primary Server and Secondary Server IP addresses or DNS names of

the primary and secondary authentication servers. A secondary server is

optional.

  Shared Secret secret key.

MS NT Domain module:

  Domain name of the Windows domain.

  Primary Domain Controller and Backup Domain Controller names of

the primary and backup Windows domain controllers. A backup domain

controller is optional.

After you change the authentication module, you do not have to restart the

Hosting Solution Engine. Changing the module does not affect users who are

currently logged on. Users who log on after the change use the new module.

Related Topic

Authentication Modules, page 7 36

SSL (HTTPS)

Use this option to obtain a permanent, signed certificate.

SSL (secure socket layer) protocol provides a secure connection between Web

clients and the Hosting Solution Engine. When you initially set up the Hosting

Solution Engine, an unsigned certificate and a CSR (Certificate Signed Request)

are automatically generated and SSL is enabled. The unsigned certificate expires

in one year.
