Chapter 6      Using Reports

Scheduling Email

Step 2

Click Run Report to display the report. A table displays in the right pane with

the following information:

Table 6 1

PIX Flow   Syslog Reporting

Column

Description

Received Time

The time the syslog message was received.

Note

Date and time are GMT.

Severity

The message severity level.

Interface

The name of the PIX firewall interface that the

message is about.

Source

The source information.

Src Port

The port used for the source information.

Destination

The destination information.

Dest Port

The port used for the destination information.

Log Msg ID

The identification number associated with the

message.

Message

The syslog message.

Scheduling Email

The Email Scheduler subtab allows you to schedule email reports. You can

configure new reports or use existing elements in a report a as a template for a

new report. If there are existing scheduled reports, you will see them listed here.

Note

To view only the reports created by you, select My Reports from the drop down

list and click Filter.

The Email Scheduler subtab allows you to:

Add an Email Report, page 6 8

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

6 7
