Chapter 5      Configuring Devices

CSS VIP Redundancy

Step 6

Click Finish to accept the configuration on the Summary page.

Related Topics

CSS VIP Redundancy, page 5 84

Creating a Virtual Router, page 5 84

Updating CSS VIP Redundancy Objects, page 5 91

Virtual Interface IP Address Criteria

Virtual interface IP address values must use the following guidelines:

It must be in the range of IP addresses defined by the IP address command

that put the CLI into interface mode. For example, if the command was IP

address 192.168.1.20/24, the address must be in the range

192.168.1.1 192.168.1.254, inclusive. The subnet broadcast addresses

cannot be used.

It must not match the local IP interface address for that subnet.

It must not match the IP address of any other redundant interfaces.

It must not match the IP address of any VIPs.

It must not match the IP address of any interface on any other node on the

subnet.

Related Topics

CSS VIP Redundancy, page 5 84

Creating a Virtual Router, page 5 84

Creating VIP Redundancy, page 5 86

Creating Critical Services

Use this option to create critical services. Critical services must be able to be

bound to VRIDs during the config.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 89
