Chapter 5      Configuring Devices

CSS VIP Redundancy

Step 6

Select VIP Redundancy to set up this option if desired.

You can enter the IP addresses here or skip this step and create just the virtual

router. The VIP redundancy can be added later, see

Creating VIP Redundancy,

page 5 86

 for details.

Step 7

Select Virtual Interface Redundancy to set up this option if desired.

You can enter the IP addresses here or skip this step and create just the virtual

router. The virtual interface redundancy can be added later, see

Creating Virtual

Interface Redundancy, page 5 88

 for details.

Step 8

Select Critical Services to set up this option if desired. See

Creating Critical

Services, page 5 89

.

Step 9

Click Finish to accept the configuration on the Summary page.

Related Topics

CSS VIP Redundancy, page 5 84

VIP Address Criteria, page 5 87

Creating VIP Redundancy

Use this option to create VIP redundancy. The VR must already be established.

Note

You can create a content rule VIP as being VIP redundant by associating it with

a VRID from a list of available VRIDs.

Procedure

Step 1

Select Configure > CSS VIP Redundancy.

Step 2

From the TOC, click VIP Redundancy.

Step 3

Click Add to select two redundant devices from the lists available. Click Next.
