Chapter 5      Configuring Devices

CSS VIP Redundancy

Step 5

From the Virtual Router Configuration form, enter the following information.

Click Next.

Caution

Never configure the preempt option on the same VR on both CSSs. Such a

configuration may result in both CSSs becoming master, which will cause

network problems.

Column Name

Description

Notes

Circuit VLAN

A circuit IP interface that is

This must already be

assigned an IP address.

configured on the router

or this task will not

work.

1

Virtual Router ID

VR identifier.

Enter an integer

between 1 and 255. You

can configure 255 VRs

per VLAN.

Device

IP address of redundant devices.

Priority

The optional priority of the VR  Enter an integer

with respect to its peers. The

between 1 and 255. A

default priority value is 100.

VR with the highest

priority usually

becomes master.

However, a higher

priority VR will not

assume mastership from

a lower priority master

unless you include the

preempt option.

Preempt indicator

The optional keyword that

To set a VR so that it

allows a higher priority VR to

will always be master,

assert mastership over a lower

set its priority to 255

priority VR. By default, a VR

and configure it with the

does not become master if the

preempt option set to

current master has a lower

true.

priority.t

1. See the CSS Routing and Bridging Configuration Guide, Version 7.30.
