Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Note

The Hosting Solution Engine parses the show real command output to get

the Connect & State for LocalDirector real servers.

Related Topics

Activating and Suspending Device Services, page 5 47

Understanding Binding

You can configure your SLB by using binding. Binding allows certain

applications or servers to be load balanced at a higher level than generic

applications or less critical servers. See the following for details on how to bind:

Binding CSS Services, page 5 76

Binding LocalDirector Services, page 5 77

Binding CSS Services

On CSS, service binding adds a service to a content rule.

Procedure

Step 1

From the content rule properties form, click Service Binding. The Service

Bindings form appears.

Step 2

To add services to the content rule or remove services from a content rule, move

the service name in or out of the Bound Services column, then click Continue.

The Modify Service Binding Weights form appears.

Step 3

Select a weight from 1 through 10, then click Save. If the binding was successful,

a confirmation window appears. If there are errors, an error message window

appears. Resolve the errors, if necessary.

Step 4

Click OK to return to the device properties window.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 76

OL 6319 01
