Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Step 4

Edit the fields and click Apply.

Step 5

To delete, select the map name check box and click Delete.

Add, Edit, or Delete Sticky Groups

A Sticky Group is a list of rules mapping an incoming connection parameter, such

as source IP address, to specific real servers. If an incoming connection matches

a rule in a Sticky Group, the SLB may attach, or stick, that connection to the real

server specified in the matching rule.

Procedure

Step 1

To add a a sticky group map, follow the steps in

Creating Policy Maps, page 5 72

and select Sticky Group. Then click Add.

Step 2

Enter the field information. The fields change based on the sticky group type you

select.

Field

Description

Group ID

Integer identifier (1 255) for the sticky

group.

Type: IP and Network Mask

Stick based on source IP address.

Type: Cookie and Cookie

Stick based on HTTP Cookie name.

Type: SSL

Stick based on SSL Session ID.

Timeout

The number of minutes the server

maintains a connection before

dropping it.

Step 3

Click Apply.

Step 4

To edit, select the group ID check box and click Edit.

Step 5

Edit the fields and click Apply.

Step 6

To delete, select the group ID check box and click Delete.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 74

OL 6319 01
