Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Creating a Policy

Procedure

Step 1

Select Configure  > Configuration.

Step 2

Click on the plus sign (+) next to the device name or IP address to expand the tree.

The device modules will display under the device.

Step 3

Click on a device module to display the module property form.

Step 4

Click Create Policy to link a policy to this device module. The policy form

appears.

Step 5

Enter the information into the form:

Field

Description

Policy Name

The name of the configured policy.

Server Farm

The name of the server farm to which

this policy is associated.

DSCP

Differentiated Service Code Point

URL Map

A group that holds multiple web

locations that are associated to this

policy.

Cookie Map

A group that holds multiple cookies.

Header Map

Source IP address information that

needs to match.

Sticky Group

Access rules

Step 6

Click Continue.

Step 7

Select the domain to which you want to add this policy. Move the domain name

from the Available Domains to the Add to Domains using the arrow keys, then

click Continue. If you do not want to add it to a domain, click Continue.

Step 8

Click OK on the confirmation window.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 70

OL 6319 01
