Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Step 4

Click on the virtual server DNS name or IP address to display the properties form.

Step 5

Click Client on the properties form in the right pane. The form appears with all

fields entered. Click Continue.

Step 6

A confirmation message appears. Click OK. The new client appears on the

configuration tree under the virtual server.

Editing or Deleting a Client

Procedure

Step 1

Select Configure  > Configuration.

Step 2

Click on the plus sign (+) next to the device name or IP address to expand the tree.

The device modules will display under the device.

Step 3

Click on the plus sign (+) next to a device module to display the module services.

Step 4

Click on the plus sign (+) next to the virtual server DNS name or IP address to

display that server's services.

Step 5

Click on the client name or IP address to edit client properties.

Step 6

Click Modify. The modify form appears. See

IOS SLB Virtual Servers, page 5 40

for details on the properties form.

Step 7

Enter your changes and click Save. Click Cancel to exit the form without saving

the changes.

Step 8

To delete a client, select the check box next to the client name in the left pane,

then click Delete. A confirmation window appears.

Step 9

Click Delete. Click OK.

The client is removed from the configuration tree.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 69
