Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Field

Description

Interval

Number of seconds between probes.

Retries

Number of failed probes that are

allowed before marking the server as

failed.

Step 6

Click Continue.

Step 7

Select the domain to which you want to add this probe. Move the domain name

from the Available Domains to the Add to Domains using the arrow keys, then

click Continue. If you do not want to add it to a domain, click Continue.

Step 8

Click OK on the confirmation window.

Editing or Deleting a Probe

Procedure

Step 1

Select Configure  > Configuration.

Step 2

Click on the plus sign (+) next to the device name or IP address to expand the tree.

The device modules will display under the device.

Step 3

Click on the plus sign (+) next to the device module that contains the probe you

want to edit.

Step 4

Click on the plus sign (+) next to the Probes folder to expand the tree. The probes

will display.

Step 5

Click on the probe name to open the properties form.

Step 6

Click Modify. The Modify Probe form appears.

Step 7

Update the fields in the form and click Save. For field descriptions, see

CSM 3.x

or Later Probes, page 5 34

. For guidelines on entering field information, see

Probe Entry Guidelines, page 5 68

.

Step 8

To delete a probe, select the check box next to the probe you want to delete. Click

Delete. A confirmation window appears.

Step 9

Click Delete. Click OK.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 67
