Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Step 6

Click Save. Click on Cancel to return to the properties window.

A validation form appears if any validation errors occur. Click OK. Correct any

errors and click Save again.

Step 7

To delete a device service, click on the service and select Delete.

A warning appears.

Step 8

Click Delete.

A confirmation or an error message window may display depending on the

outcome of the deletion task.

Creating a Probe

Procedure

Step 1

Select Configure  > Configuration.

Step 2

Click on the plus sign (+) next to the device name or IP address to expand the tree.

The device modules will display under the device.

Step 3

Click on a device module to display the module property form.

Step 4

Click Create Probe to link a probe to this device module. The probe form

appears.

Step 5

Enter the information into the form:

Field

Description

Probe Name

The name of the configured probe.

Probe Type

Type of probe for including

HTTP

,

ICMP

, Telnet,

TCP

,

FTP

,

SMTP

, and

DNS

.

Failed Interval

Number of seconds between health

checks when the server has been

marked as failed.
