Chapter 5      Configuring Devices

Configuring Server Load Balancing Services

Step 3

Click Activate inside the window. A status window appears. Successful

activations display as green text and failures display as red text. Text appears next

to device or service name. After clicking OK, the configuration tree in the left

pane refreshes.

Step 4

To suspend services, expand the desired device in the left pane and select the

check box next to the service you want to suspend.

Step 5

Click Suspend on the tree. A window displaying the services you selected

appears in the right pane. If the selected services cannot be suspended, a message

is displayed.

Step 6

Click Suspend inside the window. A status window appears. Successful

suspensions display as green text and failures display as red text. Text appears

next to device or service name. After clicking OK, the configuration tree in the

left pane refreshes.

Related Topics

Viewing Provisioned Devices, page 5 7

Activating Server Load Balancing Services, page 5 45

Configuring Server Load Balancing Services, page 5 48

Grouping Real Services by Physical Servers, page 5 77

Understanding the Configuration Tree Layout, page 5 3

Configuring Server Load Balancing Services

Use the Configuration tab to activate, suspend, create, delete, and edit services on

server load balancers. Binding (for CSS and LocalDirector devices) and device

redundancy (for CSS devices and CSM 3.x or later modules) are also supported.

For information on how to activate or suspend services, see

Activating Server

Load Balancing Services, page 5 45

. For information on viewing services, see

Viewing Provisioned Devices, page 5 7

.
