Chapter 5      Configuring Devices

Viewing Provisioned Devices

Field

1

Description

Advertise

The entry indicates whether there is a

static route to the Null0 interface for a

virtual server address.

InService Standby

The HSRP group name with which the

virtual server is associated.

1. CSM 3.x or later modules do not support all fields listed.

Step 2

If there are clients associated with the virtual server, click the plus sign (+) next

to the virtual server to expand and list the clients and real servers associated with

that virtual server.

Step 3

To view the client properties, click on a client name. A client properties form with

the following fields appears:

Field Description

Address

The client IP address. An entry of

0.0.0.0 indicates all clients.

Network Mask

The client IP network mask. An entry

of 0.0.0.0 indicates all subnets.

Exclude

The entry specifies whether to exclude

connections started by the client s from

the load balancing scheme.

Catalyst 6000 Series with SSL Service Modules

The Hosting Solution Engine supports SSL proxy services.

Expanding the Catalyst 6000 Series device name or IP address shows its

associated modules. By expanding the module number, all proxy services display.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

OL 6319 01

5 41
