Chapter 5      Configuring Devices

Viewing Provisioned Devices

IOS SLB

Expanding the IOS SLB DNS name or IP address shows its associated

virtual

server

s,

server farm

s, and

real server

s. Virtual servers appear directly under the

CSM DNS name or IP address, server farms and real servers display after you

open their respective folders. Clients appear after expanding their virtual server.

Procedure

Step 1

Click any of the list of virtual server names to view their associated real servers

and clients. See

IOS SLB Virtual Servers, page 5 40

.

Step 2

Click on the following folders to expand and view the associated servers:

IOS SLB Server Farms, page 5 37

IOS SLB Real Servers, page 5 38

IOS SLB Server Farms

Expanding Server Farms provides a list of real servers in the server farm.

Procedure

Step 1

Click a server farm name to view its properties. A properties table with the

following fields appears in the right pane:

Field Description

Name

The name of the server farm.

Bind  ID

An identification number that enables a

real server to be bound to multiple

virtual servers and report a different

weight for each one.

The bind ID is used only if you are

using Dynamic Feedback Protocol

(DFP).
