Chapter 5      Configuring Devices

Viewing Provisioned Devices

CSM 3.x or Later Virtual Servers

Procedure

Step 1

Click the virtual server names to view their properties. A properties table with the

following fields appears in the right pane:

Field

1

Description

Name

The name of the server.

Address

The IP address of the server.

Protocol

The server protocol.

Port

The port number.

SLB Special Service

The server load balancing special

service, such as FTP.

Default Server Farm

The name of the server farm with

which this server is associated.

State

The operational state of the server.

Idle Timer

The idle timeout interval in seconds.

Sticky Group

A number identifying the sticky group

to which the virtual server belongs.

Sticky Timer

The sticky timeout interval in seconds.

Sticky Network Mask

The sticky subnet mask number. Client

sessions whose source IP addresses fall

within the netmask are directed to the

same real server.

Delay Timer

The amount of time to maintain a TCP

connection after a connection has

ended.

SynGuard Count

The rate of TCP SYNs handled by a

virtual server to prevent a SYN flood

denial of service attack.

SynGuard Period

The number of unanswered SYNs

allowed before entering synguard

mode.
