Chapter 5      Configuring Devices

Viewing Provisioned Devices

Expanding the Catalyst 6000 Series device name or IP address shows its

associated modules. By expanding the module number, all virtual server names

display and server farms, real servers, probes, and policies display after you open

their respective folders.

Procedure

Step 1

Click the CSM module name to view module properties.

Field Description

Module

The slot number of the module.

Software Version

The software version of the module.

Hardware Version

The hardware version of the module.

Module Model

The model identification information

for this module.

Step 2

Click the plus sign (+) next to the CSM module to expand it and view any of the

following:

CSM 3.x or Later Virtual Servers, page 5 31

CSM 3.x or Later Server Farms, page 5 32

CSM 3.x or Later Real Servers, page 5 33

CSM 3.x or Later Probes, page 5 34

CSM 3.x or Later Policy, page 5 36

Step 3

Click the following to expand and view the associated servers:

CSM 3.x or Later Server Farms, page 5 32

CSM 3.x or Later Real Servers, page 5 33

Step 4

Click any of the list of

CSM 3.x or Later Probes, page 5 34

 to view the properties.
