Chapter 5      Configuring Devices

Viewing Provisioned Devices

A properties table with the following fields appears in the right pane:

Field Description

Name

The name of the server.

Address

The IP address of the server.

Protocol

The server protocol.

Port

The port number.

Service

The server load balancing special

service, such as FTP.

Server Farm

The name of the server farm with

which this server is associated.

State

The operational state of the server.

Idle Timer

The idle timeout interval in seconds.

Sticky Group

A number identifying the sticky group

to which the virtual server belongs.

Sticky Timer

The sticky timeout interval in seconds.

Sticky Network Mask

The sticky subnet mask number. Client

sessions whose source IP addresses fall

within the netmask are directed to the

same real server.

Parse Length

The maximum number of bytes to

parse.

Catalyst 6000 Series with CSM 3.x or Later Versions

The Hosting Solution Engine supports probes, probe headers, server farms, real

servers, virtual servers, clients, probes, policies, and maps on the CSM 3.x or later

modules.
