Chapter 5      Configuring Devices

Viewing Provisioned Devices

CSM Real Servers

Expanding Real Servers provides a list of all real servers. The associated server

farm name appears in parentheses.

Procedure

Step 1

Click on the real servers to view their properties. A properties table with the

following fields appears in the right pane:

Field Description

Address

The server IP address.

DNS Name

The DNS name of the device.

Port

The server port number.

State

The operational state of the server.

Weight

The weighting value for the virtual

server predictor algorithm. Higher

values indicate higher availability for

the server to do work.

Maximum Connections

The threshold value for the maximum

number of active connections that the

real server is assigned.

If the maximum number of

connections is reached, IOS SLB

automatically switches all further

connection requests to another server

until the connection number drops

below the specified limit.
