Chapter 5      Configuring Devices

Viewing Provisioned Devices

Procedure

Step 1

Click on the real servers on a server farm name to view its properties. A properties

table with the following fields appears in the right pane:

Field Description

Name

The name of the server farm.

Bind  Id

An identification number that enables a

real server to be bound to multiple

virtual servers and report a different

weight for each one.

The bind ID is used only if you are

using Dynamic Feedback Protocol

(DFP).

Predictor

The load balancing algorithm for

selecting a real server in the server

farm.

NAT

The client type of network address

translation (NAT). However, the NAT

client pool must already be defined.

There is only one entry per NAT client

per server farm.

NAT Client Pool

The name used to identify the client

address pool.

Backup

The entry indicates whether there is a

sticky connection backup. (This will

not appear for CSM 3.x or later

versions.)

Step 2

Click to expand the server farm name and list its associated

CSM Real Servers,

page 5 25

 and

Redirect Virtual Servers, page 5 26

.
