Chapter 5      Configuring Devices

Viewing Provisioned Devices

IOS SLB, page 5 37

Catalyst 6000 Series with SSL Service Modules, page 5 41

Note

Note, however, SSL and CSM may co exist on the same Catalyst 6000 Series

switch.

See technical documentation on Cisco.com for details.

Catalyst 6000 Series with CSM

Expanding the Content Switching Module DNS name or IP address shows its

associated server farms, real servers, and virtual servers. Virtual servers appear

directly under the CSM DNS name or IP address, real servers and server farms

display after you open their respective folders. Clients appear after expanding

their virtual server.

Catalyst 6000 hybrid devices support CSM 2.x only.

Note

If you are using a CSM 3.x or later, refer to

Catalyst 6000 Series with CSM 3.x

or Later Versions, page 5 29

.

Procedure

Step 1

Click on any of the list of

CSM Virtual Servers, page 5 28

 to view their real server

and clients.

Step 2

Click on the following to expand and view the associated servers:

CSM Server Farms, page 5 23

CSM Real Servers, page 5 25

CSM Server Farms

Expanding Server Farms provides a list of real servers and redirect virtual servers

in the server farm.
