Chapter 5      Configuring Devices

Provisioning Overview

Configure Subtab

Tree Layout Item

Description

Status

Depending on the device, the

following may display:

Number of active

connections for real or

virtual servers

State of the selected real or

virtual server

See

Showing Device Status,

page 5 75

 for steps to perform

this task.

Activate

Places the service in service.

Suspend

Places the service out of service.

Check boxes

Enables you to do an action, such

as activate, on a service.

Configuration

Delete

Removes a service and halts its

activity.

Service Chassis

Activate and Suspend

Activates or suspends all the real

services on the selected service

chassis.

Delete

Deletes the service chassis

grouping and removes the IP

addresses of that group from the

service chassis tab. The real

services are not deleted on the

device.

Edit

1

Enables you to group real

services by common physical

servers by adding IP addresses

into something called a service

chassis.

CSS VIP Redundancy

Not applicable

Enables you to set up redundant

VIP addresses and virtual

interfaces on two CSS devices.

1. The Edit button is independent of any selections in the tree.

User Guide for the CiscoWorks Hosting Solution Engine 1.8.1

5 4

OL 6319 01
