Chapter 4      Managing Devices

Managing Device Redundancy

Step 6

After device verification, click Discover to start the discovery process. You must

run discovery for these devices to show up in the configuration tree.

Step 7

After discovery is complete, you can now provision the CSS pair using the

Configure tab.

Related Topics

See the CSS Redundancy Configuration Guide at

http://www.cisco.com/en/US/partner/products/hw/contnetw/ps792/products

_configuration_guide_book09186a00801ee05c.html.

CSS VIP Redundancy, page 5 84

Entering CSM Redundant Device Information

Procedure

Step 1

After you set up the XML interface on your device modules, select

Devices >Device Management >Device Redundancy.

Step 2

Click Add to add your redundant devices.

Step 3

Select the Fault Tolerant CSM Modules check box, then click Next.

Step 4

Select two CSM modules for the redundancy pair, then click Next. CSM modules

must be 3.x or later.

Step 5

Select the validate device credentials check box and click Next.

Step 6

Click Finish after reviewing the summary window if the device redundancy was

successful. If the task was not successful, click Cancel or Back and fix the cause

of the failure, then complete the steps again.

Step 7

After device verification, click Discover to start the discovery process. You must

run discovery for these devices to show up in the configuration tree.

Step 8

After discovery is complete, you can now provision the CSM pair using the

Configure tab.
