3.1   BIOS Menu Bar

The menu bar at the top of the windows lists these selections:

Main

To configure basic system setups

Advanced

To configure the advanced chipset features

PCI/PnP

To configure legacy Plug & Play or PCI settings

Boot

To configure system boot order

Security

To configure user and supervisor passwords

Chipset

To configure chipset management features

Power

To configure power management features

Exit

To exit setup utility

NOTE

Options written in bold type represent the BIOS setup default

3.2   BIOS Legend Bar

The chart describes the legend keys and their alternates:

Key

Function

 or

General help window

Exit current menu

        arrow keys

Select a different menu

    or     arrow keys

Move cursor up/down

 or

Cycle cursor up/down

 or

Move cursor to top/bottom of the window

 or

Move cursor to next/previous page

 or < >

Select the previous value/setting of the field

 or <+> or

Select the next value/setting of the field

Load Fail Safe default configuration values of the menu

Load the Optimal default configuration values of the

menu

Save and exit

Execute command or select submenu
