Chapter 6.

Tools for Manipulating and Analyzing SELinux

An administrator's job may include analyzing and possibly manipulating the SELinux policy, as well

as doing performance analysis and tuning. This chapter discusses analysis and tuning.

For policy manipulation, you may wish to support a new daemon or discover and fix a problem, as

discussed in Chapter 8 Customizing and Writing Policy. One early step to writing policy is analyzing

existing policy so that you understand how it works. One example of this is given in Section 2.9.1 How

To Backtrack a Rule, where a macro is analyzed through the process of backtracking to the source of

a set of rules.

While some effective policy analysis can be done using standard command line text manipulation

tools, sophisticated policy analysis requires stronger tools. The simpler targeted policy consists of

more than 20,000 concatenated lines in

policy.conf

, which is derived from more than 150 macros

and thousands of lines of TE rules and file context settings, all interacting in very complex ways. Tools

such as apol are designed specifically for doing analysis of SELinux policy. This chapter discusses

these tools, which are part of the

setools

package. In addition to the GUI analysis tools seaudit and

apol, several command line tools that are useful for gathering information and statistics are explained.

Analysis is also necessary when doing performance tuning. Due to the real and potential workload

imposed by the AVC system, you may have some situations where being able to manipulate how this

works is useful to improving performance. This chapter presents some methods to tune your SELinux

installation.

In order to use these applications, you need both the

setools

and

setools gui

packages

installed. The other packages you need come with the SELinux installation:

libselinux

and

policycoreutils

.

Tip

When you are running a privileged application over ssh, meaning an application that requires you to

have root privileges, you must use the  Y option. This option enables trusted X11 forwarding:

ssh  Y root@host.example.com

The configuration requiring this is enabled by default and is new to Red Hat Enterprise Linux 4.

6.1. Information Gathering Tools

These tools are command line tools, providing formatted output. They are harder to use as part of

command line piping, but they provide gathered and well formatted information quickly.

avcstat

This provides a short output of the access vector cache statistics since boot. You can watch the

statistics in real time by specifying a time interval in seconds. This provides updated statistics

since the initial output. The statistics file used is

/selinux/avc/cache_stats

, and you can

specify a different cache file with the

 f /path/to/file

. For example, this might be useful

for reviewing saved snapshots of

/selinux/avc/cache_stats

.

avcstat

lookups

hits

misses

allocs

reclaims

frees

194658175

194645272

12903

12903

880

12402
